75 hp enclosed cab skid steer

Engine

• Model ………………………………………………….. V3307-TE5A
• Output (SAE J1995 gross) ……………………… 74.3 (55.4) / 2400 HP (kW)/rpm
• Output (SAE J1349 net) …………………………. 73.2 (54.6) / 2400 HP (kW)/rpm
• Displacement ………………………………………… 203.2 (3331) cu. in. (cc)
• Cylinders ……………………………………………….. 4
• Bore × Stroke …………………………………………. 3.7 (94) × 4.7 (120)in. (mm)
• Aspiration ……………………………………………….. Turbocharged

Loader Performance

• Rated operating capacity-35% tipping load …… 2490 (1129) lbs. (kg)
• Rated operating capacity-50% tipping load …… 3557 (1613) lbs. (kg)
• Tipping load ……………………………………………… 7112 (3226) lbs. (kg)
• Breakout force
  • Bucket ………………………………………………. 6191 (2808) lbf. (kg)
  • Lift Arm ……………………………………………… 4723 (2142) lbf. (kg)
• Lift arm path …………………………………………….. Vertical

Undercarriage

• Track Width
  • Standard …………………………………………….. 12.6 (320) in. (mm)
  • Wide ………………………………………………….. 15.8 (400) in. (mm)

Ground pressure

• Standard …………………………………………………….. 5.9 psi
• Wide ………………………………………………………….  4.8 psi
• Track rollers (per side) ………………………………….. 4
• Track ground contact length ………………………….. 56.5 (1436) in. (mm)
• Travel speed
  • Low ……………………………………………………….. 5.6 (9.0) mph (km/h)
  • High ………………………………………………………. 8.6 (13.7) mph (km/h)
• Traction force ………………………………………………. 9678 (4390) lbf. (kgf)
• Min. ground clearance …………………………………. 11.7 (296) in (mm)

Hydraulic System

• Aux. hydraulic flow Std. / High Flow ……………………… 29.8 (112.8) gpm
• Aux. hydraulic pressure ……………………………………… 3185 (224.0) psi
• Service Refill Capacities
• Hydraulic system ………………………………………………… 12.2 (46) gal
• Hydraulic tank ……………………………………………………… 4.3 (16.1) gal
• Fuel tank …………………………………………………………….. 25.0 (94.6) gal

Operating weight (Includes operator weight 165lbs.) ………. 9420 (4273) lbs (kg)

75 hp enclosed cab skid steer w/ joystick controls
