Kubota Skytrack 6042

Performance

• Rated Capacity ……………………………………………………. 6,000-lb / 2,722-kg
• Maximum Lift Height ……………………………………………… 42-ft 4-in / 12.9-m
• Load at Max Height ……………………………………………… 6,000-lb / 2,722-kg
• Maximum Forward Reach ……………………………………… 29-ft 6-in / 9.0-m
• Load at Max Reach ………………………………..…………… 1,200-lb / 544-kg
• Frame Leveling …………………………………………………… 10 Degrees
• Lift Speed (Boom Retracted) Up ………………………………… 13.3 sec
• Lift Speed (Boom Retracted) Down ……………………………… 11.3 sec
• Boom Speed Extended …………………………………………… 13.8 sec
• Boom Speed Retracted …………………………………………… 12 sec
• Top Travel Speed (4-Speed) ……………………………………… 15 mph / 24.1 km/h
• Drawbar Pull (Loaded) …………………………………………… 16,715-lb / 74-kN
• Outside Turning Radius …………………………………………… 12-ft 7-in / 3.8-m
• Operating Weight ………………………………………………. 19,100-lb / 8,664-kg

Engine

• Make and Model……………………………………………. Deutz TCD2.9 L4
• No. of Cylinders ……………………………………………. 4
• Displacement ……………………………………………. 177 cu in / 2.9 L
• Gross Power Basic ………………………………………. 74 hp / 55 kW @ 2,400 rpm
• Maximum Torque @ 1600…………………..……………. 221lb-ft / 300 Nm
• Fuel Tank Capacity ………………………………………. 28 gal / 106 L

Transmission

• Hydrostatic 1-speed forward and 1-speed reverse
• Axles
• Full-time planetary 4-wheel drive.
• Oscillating rear axle with Stabil-Trak system.

 Brakes

• Hydraulically actuated inboard wet disc brakes with inching feature. Emergency brake.

Tires

• Standard 15-19.5 Pneumatic
• Optional Foam-Filled, Solid, Turf , Non-marking (Pneumatic or Foam-Filled)

Cab

• Adjustable suspension seat with retractable seat belt
• Certified ROPS/FOPS structure
• Integrated arm rest
• High visibility seatbelt
• Rear view mirrors
• Single joystick controls

Steering 4-Wheel

• Power steering.
• Operator selectable 4-wheel circle, 4-wheel crab, 2-wheel front.

Instruments

• Fuel gauge
• Hourmeter
• Large LCD Display for Diagnostics
• Temperature gauge
• Speedometer
• Tachometer

 Hydraulic System-Implement

• Capacity ………………………………………………………. 37.0 gal / 140 L

Skytrack 6042
